Beryllium Copper Sheet

Grade: C17200, C17300, C17500, C17510
Thickness: 3mm - 100mm
Width: Max 1000mm
Description Technical Information Packaging More Review
Description

Guangdong Metal Corporation is a leading beryllium copper sheet supplier and manufacturer.

Beryllium copper (BeCu), also known as copper beryllium (CuBe), beryllium bronze and spring copper, is a copper alloy with 0.5—3% beryllium and sometimes other elements. Beryllium copper combines high strength with non-magnetic and non-sparking qualities. It has excellent metalworking, forming and machining properties. It has many specialized applications in tools for hazardous environments, musical instruments, precision measurement devices, bullets, and aerospace.

Beryllium alloys present a toxic inhalation hazard during manufacture. Beryllium copper is a ductile, weldable, and machinable alloy. Like pure copper, it is resistant to non-oxidizing acids like hydrochloric acid and carbonic acid, to plastic decomposition products, to abrasive wear, and to galling. It can be heat-treated for increased strength, durability, and electrical conductivity. Beryllium copper attains the greatest strength of any copper-based alloy.

If you want to know more about our beryllium copper sheet or beryllium copper strip please feel free to contact us, we will reply you within 24 hours.



  • 1) Grade: C17200, C1720, C17000, C17300, C17500, C17510, Qbe2,Qbe1.9, Qbe1.7, Qbe0.6-2.5, Qbe0.4-1.8, Qbe0.3-1.5, Qbe1.9-0.1

    2) Thickness: 3mm - 100mm

    3) Width: ≤1000mm

    4) Length:≤2000mmm

    5) Temper: TB00, TD01-04, TF00, TH01-04, TM00-08, or according to requirements

  • 1) Rally intensity

    Beryllium copper maximum tensile strength can be achieved 140kg/mm2, through heat treatment, so the role may be able to tolerate high tension bending the flexible material.

    2) High thermal conductivity

    Beryllium copper in the range of high-temperature materials in the field of 0.25Cal / (cm-sec-C) wide and high temperature performance.

    3) Good shape

    Beryllium copper solution through the annealing process so that it softened, it is possible to create complex shapes, and you can go through heat treatment and access to the highest mechanical properties.

    4) Anti-Corrosion

    Beryllium copper has a good anti-corrosion, and is almost comparable to Yeung copper-nickel alloy.

  • 1) Oilfield tools

    2) Aerospace landing gears

    3) Robotic welding

    4) Mold making

    5) Musical instruments

    6) Precision measurement devices, etc.

  • Spectrum Test

    Grain Size Test

    Hardness Test

    Tensile Strength Test

    Elongation Test

Technical Information

Manufacturing of Beryllium Copper Sheet / Plate

Packaging

Packaging of Beryllium Copper Sheet / Plate

Guangdong Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) Guangdong Metal Standard

2) Customization





More

Applications of Beryllium Copper Sheet / Plate:

Beryllium copper and its variety of alloys are utilized in very specific, and often tailor made applications such as oilfield tools, aerospace landing gears, robotic welding, and mold making applications. Additional Non-magnetic properties make it ideal for down-hole wire line tools. These specific applications are the reason this copper is known as spring copper and other various names.

1) Oilfield tools

2) Aerospace landing gears

3) Robotic welding

4) Mold making

5) Musical instruments

6) Precision measurement devices, etc.
